The low-level wind profile radar is a flexible deploying atmospheric detection and remote sensing device which is used in low-level clear sky. It adopts frequency modulation and persistent wave system and solid-state active phased array technology, which can provide high precision wind data of 20m~600m low-level in time. This product can be installed and fixed in car. It is used for observation and numerical forecast of low-level atmospheric wind filed, environmental monitoring, small and medium scale disastrous weather monitoring and early warming, airport wind field detection and power wind field exploration.

Advantage

a flexible deploying atmospheric detection and remote sensing device which is used in low-level clear sky.

high spatial and temporal resolution high detection precision

good maneuverability

simple structure

Detection Range Minimum detection height : 20m
Maximum detection height: 600m
Wind direction 0~360
Detection Error (RMS) Horizontal wind speed: 1.5m/s
Vertical airflow: 0.2m/s
Wind direction: 10
Resolution High resolution: 3.75m, 15m, 60m
Time resolution: 1min
System Lose 4kw
Working Mode FM CW
